Extremely bright RGBA color changing FlexLED Tape
Suitable for on-camera use, or anywhere a high-quality LED product is required.
Indoor and weatherproof strips have 3M double-sided tape on the back which makes installation as easy as peel n stick.
Waterproof must be mounted using silicone (not provided)
Maximum recommended length in order to prevent line-loss is 5m. (16.4')
Controller, Power supply and Extension Cables sold separately
Controller, power supply and extension cables sold separately
Please call 1.800.924.1585 or email info@mossled.com to inquire.
For specifications on Weatherproof and Waterproof product please download specifications sheet below.
Soldering Guidelines:
Soldering iron should be between 360°C and 372°C. Please ensure not to heat each solder pad for longer than 3 seconds otherwise separation of the solder pads can occur.
Pricing is for 5 meters (16.4')
SPECIFICATIONS - INDOOR PRODUCT
| Product Type |
: |
240 RGBA 24V (Individual Diodes) |
| Product Code |
: |
I24VRGBA12001210 |
| CRI |
: |
N/A |
| Kelvin |
: |
RGBA |
| PCB Color |
: |
White |
| Current, Rating |
: |
0.79 A / meter |
| Voltage |
: |
24 VDC |
| Wattage |
: |
19.2 W / meter |
| CC / CV |
: |
Constant Voltage |
| IP Rating |
: |
IP43 |
| Lumens @ Full |
: |
1300 lm / meter |
| Lumen / Watt |
: |
67.7 |
| Lifetime* |
: |
50,000 hours |
| Cutting Length |
: |
10 CM |
| LED Quantity |
: |
240 LED / meter |
| Number of Contacts |
: |
5 |
| LED Type |
: |
1210 |
| Copper Quantity |
: |
3 Oz. |
| Temperature, Operating, Maximum |
: |
70 C |
| Temperature, Operating, Minimum |
: |
-40 C |
| Agency Ratings |
: |
UL - E489028, CE, RoHS |
| PCB Width |
: |
14MM |
| Maximum Recommended Length |
: |
5 meters |
| Viewing Angle |
: |
120 |
| Adhesion |
: |
200MP 3M |
