Dim-To-Warm (Auto-Dim) FlexLED Dynamic White 1800K - 2700K 24V

Auto-Dimming high density FlexLED Tape

1800K - 2700K CRI 95+

New for the residential and commercial markets is our Auto-Dim (Dim to Warm) FlexLED strip.  Designed to work with any PWM dimming circuit it starts at 2700k when at full and smoothly dims down to 1800k both reducing brightness and colour temperature at the same time. High density of 224 LED/meter and high CRI allows for mimicking of traditional halogen and incandescent sources. This LED works directly with our FFDCV dimmable drivers and is suitable for most residential, commercial, and industrial lighting systems. (TRIAC / 0-10V / 1-10V / 10V PWM / Potentiometer)

Suitable for residential, industrial, and commercial applications where high CRI white output and auto-dimming is required.  Our standard 5 meter reel (16'4") is designed to work within Class 2 parameters drawing only 87 watts.

Single bin LED chip ensures CCT accuracy within +/- 100k.

TESA 4965 high tack double-sided tape on the back makes installation as easy as peel n stick.  When used in damp or wet locations it is advised to use silicone caulking or glue to ensure proper adhesion.

Soldering Guidelines:
Soldering iron should be between 360°C and 372°C.  Please ensure not to heat each solder pad for longer than 3 seconds otherwise separation of the solder pads can occur.

Controller, Power supply and Extension Cables are sold separately.
Custom Color Temperatures are available.  Please contact us for specifics.

For specifications on Weatherproof and Waterproof product please download specifications sheet below.

Pricing is for 5 meters (16.4')

SPECIFICATIONS - INDOOR PRODUCT

DOWNLOADS

1. Specification Sheet

2. UL Certificate of Compliance
