SPECIFICATIONS - INDOOR PRODUCT
| Product Type | : | ML24 Bi-Colour 27k - 56k |
ML24 3000k |
ML24 5600k |
| Product Code | : | 24VML24BC27561000MMW | 24VML24T301000MMW | 24VML24D561000MM |
| CRI | : | ≥95 | ≥95 | ≥95 |
| Kelvin | : | 2700k - 5600k | 3000k | 5600k |
| PCB Color | : | White | White | White |
| Current, Rating | : | 9.67 A / 1 meter panel | 9.67 A / 1 meter panel | 9.67 A / 1 meter panel |
| Voltage | : | 24 VDC | 24 VDC | 24 VDC |
| Wattage | : | 232 W / panel | 232 W / panel | 232 W / panel |
| CC / CV | : | Constant Voltage | Constant Voltage | Constant Voltage |
| IP Rating | : | IP43 | IP43 | IP43 |
| Lux @ Full | : | 28,010 | 27,775 | 28,250 |
| FC @ 36" | : | 658 | 644 | 672 |
| Lifetime* | : | 30,000 hours | 30,000 hours | 30,000 hours |
| Cutting Length | : | 1.6CM | 1.6CM | 1.6CM |
| LED Quantity | : | 2,880 / panel | 2,880 / panel | 2,880 / panel |
| Number of Contacts | : | 3 | 3 | 3 |
| LED Type | : | 2835 | 2835 | 2835 |
| Copper Quantity | : | 3 Oz. | 3 Oz. | 3 Oz. |
| Temperature, Operating, Maximum | : | 70 C | 70 C | 70 C |
| Temperature, Operating, Minimum | : | -40 C | -40 C | -40 C |
| Agency Ratings | : | UL - E489028, CE, RoHS | UL - E489028, CE, RoHS | UL - E489028, CE, RoHS |
| PCB Width | : | 240 MM | 240 MM | 240 MM |
| Maximum Recommended Panels | : | 2 X 1 Meter Panels | 2 X 1 Meter Panels | 2 X 1 Meter Panels |
| Viewing Angle | : | 120 degree | 120 degree | 120 degree |
| Adhesion | : | 3M 300MP | 3M 300MP | 3M 300MP |
